The Garcia Residence





Living room. Built-in couch, lava-rock fireplace. Steps to ground below begin at depression in lower right side of picture. Lautner on couch, left.
Photo by Julius Shulman


Simplified section




section through bldg.

Section through building. Steel beams, curving at ends, provide the structural support for the floor and roof, so that no load-bearing walls are necessary.




End of building showing steel supports, edge of stair to below.
Photo by Alan Weintraub




Simplified plan
